Introduction: USB Wii Classic Controller

This project will show you how to create a real USB game pad using a Wii Classic Controller.



Through the steps, you will learn about:
  • How USB works
  • How I2C works
  • How to read data from the Wii Classic Controller
Some of these pre-requisite skills would be nice
  • General electronics
  • AVR programming
The code will be based on V-USB, and the circuit will be based on a implementation V-USB example circuitry called USnooBie.

The entire project is provided as a ZIP file download below. Also see below for a flowchart of how the code will work.



Step 1: Using the AVR With V-USB

For the microcontroller, we'll be using a ATmega328P. This microcontroller has enough memory resources and a built-in TWI/I2C peripheral to accomplish our goals. However, it does not have built-in USB, which is a problem that we are going to solve using V-USB.
"V-USB is a software-only implementation of a low-speed USB device for Atmel’s AVR® microcontrollers, making it possible to build USB hardware with almost any AVR® microcontroller, not requiring any additional chip."

- V-USB official website

V-USB uses a set of hardware and some very special assembly programming techniques to bit-bang the non-return-to-zero (NRZ) binary code that USB uses to communicate. The files provided by V-USB will be compiled into our program in order to create a USB device with our ATmega328P

Please visit the download section of V-USB's website to obtain a copy of the latest version. In my project source code, it's already included.

To compile V-USB into your project...

  1. Make sure you've defined the processor and clock speed correctly (V-USB only supports certain clock speeds)
  2. Copy the folder "usbdrv" from the downloaded package into your project folder
  3. In your project manager or makefile, include "usbdrv.c" and "usbdrvasm.S", such that the object file that's generated will become linked into your project
  4. Inside the folder "usbdrv", there is a "usbconfig-prototype.h", copy that file into your main project directory, and rename it to "usbconfig.h"
  5. Edit "usbconfig.h", this will be explained in detail later
  6. Use "#include" statements to include "usbconfig.h" and then "usbdrv/usbdrv.h"
  7. Make sure that "usbdrv/usbdrv.h" is able to find "usbconfig.h", if it's not able to, use the use "-I" to your makefile or edit "usbdrv/usbdrv.h" to change the file path to "usbconfig.h" (to "../usbconfig.h")
Then your project must implement the some functions...
  • You must initialize V-USB, and then enable interrupts in the AVR
  • It's almost a standard practice to fake disconnect, wait a few milliseconds, and reconnect to the computer, during starting the code. This makes sure your device and computer are in a "reset" state to start off.
  • A request handler function must be implemented, even if you don't perform real actions in it, you must implement it yourself. Look for "usbFunctionSetup" later.
    • In our example, we need to use this function to handle two special requests, you'll see it later
  • The gamepad is a HID device, a USB HID Report Descriptor must be written and stored in your code
More Reading:

Step 2: Building the Circuit

To simplify the process of creating V-USB based devices, I created the USnooBie.

USnooBie official site





You can buy it from Seeed Studio, it should come with all the parts you need and the bootloader all ready to go.
The USnooBie is a microcontroller kit that does not require any sort of AVR programmer or USB-to-serial converters to load and run compiled code. It's hardware design allows the user to develop low cost USB devices with Atmel's AVR ATmega microcontrollers. It can also be used to develop projects which are not USB devices. It is even compatible with Arduino.


USnooBie Assembly Instructions and Parts Breakdown

This is a short version of the official assembly guide, visit the official assembly guide to read more details.

Assemble the USnooBie according to these steps. The smaller components must be soldered first, before the larger components, this makes assembly easier. The parts required are also described here so this document also acts as a part list so you may find replacement components.

Two 68 ohm resistors

These resistors limit the current between the USB device (microcontroller) and the USB host (computer) on the D+ and D- lines of the USB bus. They act as terminating resistors, so the terminating impedance matches the USB cable's characteristic impedance, reducing signal reflections. They are small and low components and are thus soldered first.

These should be two 68 ohm 1/4 watt +/- 5% tolerance carbon film resistors.

D- pull-up resistor

This resistor is placed on the D- line of the USB bus. When D- is pulled up, it indicates to the USB host that the USB device is a low speed USB 1.1 device. This resistor is usually 2.2 kilo-ohm if pulling up to 5V and 1.5 kilo-ohm when pulling up to 3.3V. 1.8 kilo-ohm works well with both 5V and 3.3V.

This resistor should be one 1.8 kilo ohm 1/4 watt +/- 5% tolerance carbon film resistor.

Note: the original design used a 1.7 kilo ohm resistor, the kit being sold is provided with a 1.8 kilo ohm resistor, either should work. The schematics may show a 1.7 kilo ohm resistor (typo, sorry).

LED current limit resistor

This resistor limits the current for the power indication LED. If this current is not limited, then the LED's lifespan is drastically reduced.

This resistor should be a 330 ohm 1/4 watt +/- 5% tolerance carbon film resistor.

Two 3.6V Zener diodes

These 3.6V Zener diodes ensures that the signal on the D+ and D- lines of the USB bus are within acceptable limits. This allows the USB device to run at 5V without damaging other devices on the USB bus.

These should be 1N5227B 3.6V Zener diodes. There have been reports that certain Zener diodes will not work. 200mW Zener diodes may not work but 500mW Zener diodes will (source: http://forums.obdev.at/viewtopic.php?f=8&t=4677).

Ensure that you place these parts in the correct orientation as indicated by the symbol on the PCB. The triangle on the symbol points in the direction which the stripe on the diode should be.

Reverse current protection diode

This part is not included in the kit provided by Seeed Studio. You must replace this part with a jumper wire or else the USnooBie will not receive power from the USB port.

Power indicator LED

This LED indicates that there is power on the power bus. Note that it does not indicate the amount of power, so even if it is lit, it does not guarantee that certain components are receiving enough voltage.

This must be a 3mm diameter standard LED.

This LED may be omitted if you want to save power or you want a "stealthy" USB device.

Ensure that you place this part in the correct orientation as indicated by the symbol on the PCB. If you are unable to determine the direction of the LED, then you should test the LED before installing it. The "flat side" should be the cathode, which should be negative to light up, while the "round side" is the anode, which should be positive to light up. Use a 3V coin cell battery to perform this test really quickly to avoid damaging the LED.

USB A male connector

This allows the USnooBie to be plugged directly into a USB port, or you can buy a USB extension cable from the dollar store to connect it.

Two tactile SPST momentary on push button switch

One button is used to reset the AVR microcontroller, the other button acts as a bootloader activation button. Upon reset, the AVR runs the bootloader section code which checks whether or not the bootloader activation button is held down. If it is held down, the bootloader becomes a USBasp device so you may load your own code into the AVR microcontroller. If it is not held down, then the bootloader jumps to the application section to run the code you have previously loaded.

This bootloader activation button is placed on the D- line, when pressed during normal use (not during boot time), it will cause the USB device to appear disconnected from the USB host. This is useful in certain situations when you require your device to disconnect without physically disconnecting.

The Omron B3F-1000 tactile SPST momentarty on push button switch should be used here.

28 pin DIP chip socket

A 28 pin DIP chip socket is used to hold the AVR ATmega microcontroller.

Due to the placement of the three tandum capacitors, a 28 pin DIP chip socket must be used (or two 14 pin DIP chip sockets, the PCB layout is designed to allow this) to hold the AVR ATmega microcontroller. The chip socket should have a gap down its center, giving you room to place the three capacitors. Solder in the sockets first, then insert the capacitors through the gap. See the picture provided.

Ensure that you place this part in the correct orientation as indicated by the symbol on the PCB.

Do not insert the chip into the socket until the board passes some simple testing (later steps).

Three monolithic capacitors

The 0.1uF capacitor is a decoupling capacitor which smooths out fine ripples on the power bus. The code on this capacitor should be 104 (meaning 0.1uF).

The two 27pF capacitors cleans the signals from the 12 MHz crystal. The code on these capacitor should be 270 (meaning 27 pF).

These capacitors can be monolithic or ceramic.

12 MHz crystal

The 12 MHz crystal is the clock source for the AVR microcontroller. It is 12 MHz because that's the best clock speed for 3.3V opertation that is supported by V-USB.

The crystal must be a 12 MHz crystal in a HC49 package. Low profile packaging is prefered, as long as the pin spacing is the same.

Voltage selection jumper

A three pin header is used to select the voltage on the power bus, a shunt block is used on the 3 pin header to make the connection that makes the selection. This allows you to choose between using the 5V power supply from the USB port or using the 3.3V power supply provided by the 3.3V voltage regulator.

Do not install the jumper shunt block until the board has passed some tests (described in later steps).

PTC resettable fuse

This fuse protects the USB host from damage during short circuit situations by cutting off current. The fuse will heat up when current reaches unacceptable levels and it will become a resistor, limiting the current drastically, and when the fuse cools down, it loses its resistance and conducts current again. This will protect your computer if you accidentally short your power bus. Since it resets itself automatically after cooling down, it will never need to be replaced (unlike an ordinary fuse).

Note that the USB bus can only supply up to 500mA of current, the fuse provided will build up resistance once it reaches 250mA and cut off power completely if the current reaches 500mA. For most applications, this amount of power is enough, if you require more power, consider utilizing an external power source as the power supply, instead of your computer.

This component should be the RXE025 from Tyco Electronics, it is the same PTC resettable fuse sold on SparkFun. It has a I-hold of 250mA and I-trip of 500mA.

4.7 uF electrolytic capacitor

This capacitor smooths out large slow ripples on the power bus, and acts as a small reservoir during sudden current draw.

This should be a 4.7 uF electrolytic capacitor rated at 10 volts in radial packaging.

Ensure that you place this part in the correct orientation as indicated by the symbol on the PCB. The capacitor should have a strip on the side with negative (minus signs) symbols, which corresponds to the negative side of the capacitor symbol on the PCB (opposite to the pad with the positive + symbol).

3.3V low dropout voltage regulator

This should be a TC1262 in TO-220 packaging. It is a low dropout voltage regulator that will step down the 5V USB power down to 3.3V.

This may be omitted if you do not want a 3.3V power source.

Ensure that you place this part in the correct orientation as indicated by the symbol on the PCB. The metal heatsink on the voltage regulator should face towards the inside of the board (as indicated by the thicker silkscreened line).

This component must be a 3.3V low dropout voltage regulator in 3 pin TO-220 packaging. Microchip's TC1262 or similar may be used.

Male headers

There are three groups of male headers. One long group that has 16 pins, two shorter groups with 6 pins each.

These male headers allow you to insert the USnooBie into a breadboard. These headers should go on the bottom of the PCB.

To make soldering these header pins easier, you can try inserting them into the breadboard first, and then placing the USnooBie PCB on top, so that the breadboard keeps the header pins straight and holds them in place for you while you solder from the PCB's top side.

Continuity testing the ground

Use a multimeter's continuity tester to check that all pins/pads/joints that are supposed to be ground are connected to each other and only each other.

If this test passes, then you should be able to check the voltages while powered up without worrying too much about a short causing massive current draw.

Continuity testing the power bus

Use a multimeter's continuity tester to check that all pins/pads/joints that are supposed to be on the power bus are connected to each other and only to each other. Do this while the voltage selection jumper shunt block is not installed.

Voltage check

Plug in the USnooBie into a powered USB port and check the voltages on the pads/pins/joints which are supposed to be 5V. Do the same for the ones that are supposed to be 3.3V.

Install the jumper shunt block on to the voltage selection jumper pin header. Check that you are able to select the voltage on the power bus by moving the jumper shunt block. When there is power on the power bus, the power indicator LED should also light up.

Insert the microcontroller

Insert the AVR ATmega328P microcontroller into the 28 pin DIP chip socket to finish constructing the USnooBie.

If the correct bootloader is already loaded on the microcontroller and the microcontroller's fuse bit settings are correct, you can start to use the USnooBie (if you buy it from Seeed Studio, then this is done for you already). Follow the instructions for loading code onto the USnooBie to check that it functions as a USB device when connected to a computer.



Usage Guide


This is the short version of the official usage guide, go visit the official usage guidefor more details.



To enter the bootloader, hold down the bootloader-activation button, then press and release the reset button, then release the bootloader-activation button. The bootloader should appear to your computer as an USBasp programmer, so you may now use it as though you were using an USBasp with AVRDUDE.

A typical AVRDUDE command would start with "avrdude -c usbasp -p atmega328p", and to load a hex file into flash memory, it looks like "avrdude -c usbasp -p atmega328p -U flash:w:filename.hex". You will not be able to modify any fuse-bits, which prevents you from "damaging" the bootloader.

There's a good chance that you'll require the USBasp drivers in order for the USBaspLoader bootloader to work. The drivers can be found here

Step 3: Understanding USB

USB uses two wires, usually called D+ and D-, to transmit serial data using non-return-to-zero coding. These two wires are a differential pair, meaning D-'s signal will always be D+'s inverted state. This allows it to transfer data really fast over a long cable (5 meter cable at 480 Mbit/s if using USB 2.0 high speed), read this for more http://en.wikipedia.org/wiki/Differential_pair

USB busses have a device and host, the computer is usually the host, our game pad is a device, more specifically, a HID (human interface device). It is important to note that the host always initiate communication, or the host checks the device frequently to see if it has anything to say. The device does not have the ability to initiate communication, it can only wait until it's spoken to.

There are pull-up resistors on D+ or D- depending on whether or not the device is USB 1.0, USB 1.1, or USB 2.0. The presense of these pull-up resistors is also how a computer knows when something has connected. On the USnooBie and most V-USB circuitry, the pull-up resistor is always on the D- signal since V-USB is only capable of implementing low speed USB devices.

The two 68 ohm resistors on the D+ and D- signals are terminating resistors, their impedance are calculated (taking into account the AVR's internal circuitry) to be matched with the characteristic impedance of the USB cable. This minimizes signal reflections. Read  http://en.wikipedia.org/wiki/Transmission_line to learn more.

When a device connects to a host, the host tries to "enumerate" the device. If it fails to do so (device not responding, or responding with garbage), that's when Windows says "device not recognized".

The host and device talks over channels called "endpoints", endpoints are identified by a number. There are some endpoints that a reserved for special use, while others can be configured to operate in different modes (interrupt, bulk, etc).

The host will always first use the "control endpoint" (endpoint 0) first to request a description of the device, this "descriptor" will contain the device identifiers (vendor ID and product ID, etc), along with its device class, subclass, etc (HID like a mouse or keyboard? or maybe mass storage?). Then the configuration descriptor is requested, which also contains the number of endpoints available on the device. Each endpoint has its own descriptor as well. All of this data are sent as packets of data bytes representing a well known specified data structure.

V-USB and other USB frameworks/stacks have APIs and other methods to allow the programmer to change the content in the descriptors. You need to first understand each descriptor, and then check the documentation on V-USB to see how to change them (I'll show you later).

The host makes the requests by sending "setup packets" to the "control endpoint". Setup packets have a defined structure making it easy for the device to understand what the host wants. V-USB (and similar frameworks) usually handles the default setup packets. A programmer can write drivers that sends custom setup packets, in which case the firmware must handle the setup packets manually, V-USB (and others) provides some methods to help with that.

Later on in this instructable, I have included a dump of the descriptors captured by my USB traffic analyzer. You can take a look and match it up with USB specifications to see what each portion represents.

Once all the descriptors have been retrieved from the device, the host can then understand the device and communicate with it. We'll look at all the descriptors in detail later.

I have another Instructable which shows you how to build a USB keyboard that types out the code stored in RFID tags: https://www.instructables.com/id/USB-RFID-Reading-Keyboard/

Homework: Read USB in a Nutshell http://www.beyondlogic.org/usbnutshell/usb1.shtml which is pretty much a USB bible

Important Note: Most of the USB terminology is from the perspective of the host (the computer), so the words "in" and "input" means from the device to the host, and the words "out" or "output" mean from the host to device.

Step 4: USB Descriptors

Here's the USB in a Nutshell page on descriptors, you need to refer to this some times.

To recap, we need to worry about the device descriptor, configuration descriptor, interface descriptor, endpoint descriptor, and string descriptors. There is also a USB Human Interface Device Report Descriptor that we will need to write later.

The device descriptor will tell the computer information about the device in general. Info such as the USB standard it meets, it's device class & device subclass, protocol, vendor, product ID, and a few optional strings such as product name, manufacture name, and serial number. It will also indicate how many configurations there are available for this device (this is almost always just one).

For this project, the device class is set to 0, meaning "defer to interface", so our interface descriptor will describe this device as a Human Interface Device (HID). The device subclass and protocol are irrelevant. The vendor ID and product ID can be anything (sort of, we'll talk about this later). In the source code, I've set the manufacture string to my website, and the name of the device is "Wii Pad".

Each configuration descriptor will indicate how the device is powered, how much power it needs, and how many interfaces it has. There is also a string that describes each configuration (I haven't seen this used). Different configuration can be selected but usually there is only one available configuration.

For this project, the configuration will indicate that this gamepad will be powered by the USB port and it will need about 100 mA of current (no it doesn't, but 100 is a nice number and well over our real requirements). There is only one interface.

Each interface descriptor contains info about the number of endpoints in the interface, and then the interface class, interface subclass, and interface protocol of this particular interface.

For this project, we will be using endpoint #0, which is the "control endpoint" (default for standard requests from the computer), and endpoint #1, which is a "interrupt-in" endpoint that we'll be sending USB HID reports (these reports contain the gamepad data) through. The class will be 0x03, indicating Human Interface Device (HID), the subclass and protocol are both 0x00.

More Reading:

Step 5: USB HID Reports and Report Descriptors

When you make a HID device, the device sends short reports at regular intervals to the computer. These reports contain information about which buttons are pressed and how much the joysticks have moved. However, in order for the host to understand the data format, the device must "describe" the reports to the host. This is why we write a USB HID report descriptor.

Take a look at your Wii Classic Controller. It has 15 buttons (round up to 16 for simplicity), and two joysticks. This means we need to send 15 bits of data for the buttons, and 4 numbers, one for each axis of joystick data. We define our data format to look like this:

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Button Button Button Button Button Button Button Button
Byte 1 Button Button Button Button Button Button Button Button
Byte 2 Left Stick X Axis as Signed Char Integer
Byte 3 Left Stick Y Axis as Signed Char Integer
Byte 4 Right Stick X Axis as Signed Char Integer
Byte 5 Right Stick Y Axis as Signed Char Integer

And then we can define a data structure in C/C++
struct gamepad_report_t { uint16_t buttons; int8_t left_x; int8_t left_y; int8_t right_x; int8_t right_y; }Writing a report descriptor involves describing a usage context first, and then describing the meaning of the data relative to the usage context, and then describing the data in terms of its range and size.

First, make the computer understand that the device is a gamepad

USAGE_PAGE (Generic Desktop) USAGE (Game Pad) COLLECTION (Application) COLLECTION (Physical) ... END COLLECTION END COLLECTIONThen describe the button data (16 bits)
USAGE_PAGE (Button) USAGE_MINIMUM (Button 1) USAGE_MAXIMUM (Button 16) LOGICAL_MINIMUM (0) LOGICAL_MAXIMUM (1) REPORT_COUNT (16) REPORT_SIZE (1) INPUT (Data,Var,Abs)Then describe the 4 axis data as signed 8-bit integers
USAGE_PAGE (Generic Desktop) USAGE (X) USAGE (Y) USAGE (Z) USAGE (Rx) LOGICAL_MINIMUM (-127) LOGICAL_MAXIMUM (127) REPORT_SIZE (8) REPORT_COUNT (4) INPUT (Data,Var,Abs)
  • NOTE: Z is used to represent the right stick's X axis, Rx is used to represent the right stick's Y axis. This doesn't make sense but this is how most existing USB game pads work. I have tested this using Battlefield Bad Company 2, it works.
  • NOTE: Use "absolute" for something like joysticks, but "relative" for things like mouse.

Finally, the report descriptor looks like:
USAGE_PAGE (Generic Desktop) USAGE (Game Pad) COLLECTION (Application) COLLECTION (Physical) USAGE_PAGE (Button) USAGE_MINIMUM (Button 1) USAGE_MAXIMUM (Button 16) LOGICAL_MINIMUM (0) LOGICAL_MAXIMUM (1) REPORT_COUNT (16) REPORT_SIZE (1) INPUT (Data,Var,Abs) USAGE_PAGE (Generic Desktop) USAGE (X) USAGE (Y) USAGE (Z) USAGE (Rx) LOGICAL_MINIMUM (-127) LOGICAL_MAXIMUM (127) REPORT_SIZE (8) REPORT_COUNT (4) INPUT (Data,Var,Abs) END COLLECTION END COLLECTION
Now that we have a report descriptor, how do we make our AVR tell this stuff to the computer? Go download the official "HID Descriptor Tool" from http://www.usb.org/developers/hidpage/ . Use it to put this stuff in, and the tool will generate the correct binary array for you.




When you save your result, go to "File" -> "Save As", and then make sure you choose "Header File (*.h)" in the save dialog. Then open the file, it should look like

char ReportDescriptor[ some number here (size of array)] { a lot of bytes here };
Great, the size of array needs to be copied into V-USB's "usbconfig.h" where it says "USB_CFG_HID_REPORT_DESCRIPTOR_LENGTH", and "char ReportDescriptor" needs to be renamed to "PROGMEM char usbHidReportDescriptor" so that it is stored into the AVR's flash memory. You end up with something like:
That piece of code, plus the struct typedef we did earlier, is included in our project source code (see whole source code) later.

More Reading:

Step 6: Handling USB Standard Requests

The host will eventually send some requests to our device, maybe to request a descriptor, the report, or set some parameters (notably, the "idle rate").

Each request comes in a standard format, which can be mapped to a data structure that describes the request in terms of its size, meaning, and contents. It looks like:
typedef struct usbRequest{ uchar bmRequestType; uchar bRequest; usbWord_t wValue; usbWord_t wIndex; usbWord_t wLength; }usbRequest_t;
V-USB's API requires you to make a function called "usbFunctionSetup" which takes 8 bytes in. These 8 bytes are casted to the type "usbRequest_t". Then, the request is decoded and fulfilled. There are three things we must handle:
  • Request for the report
  • Request for the report descriptor
  • Request to set the idle rate

So the piece of code looks like:
static unsigned char idleRate; unsigned char usbFunctionSetup(unsigned char data[8]) { usbRequest_t *rq = (void *)data; if ((rq->bmRequestType & USBRQ_TYPE_MASK) == USBRQ_TYPE_CLASS) /* class request type */ { if (rq->bRequest == USBRQ_HID_GET_REPORT) /* wValue: ReportType (highbyte), ReportID (lowbyte) */ { usbMsgPtr = &gamepad_report; return sizeof(gamepad_report); } else if (rq->bRequest == USBRQ_HID_GET_IDLE) { usbMsgPtr = &idleRate; return 1; } else if (rq->bRequest == USBRQ_HID_SET_IDLE) { idleRate = rq->wValue.bytes[1]; } } else { // no vendor specific requests implemented } return 0; } This piece of code goes into the whole source code.

More Reading:

Step 7: Connecting the Wii Classic Controller

Since you do not want to cut the cable on your Wii Classic Controller, go buy a cheap extension cable for Wiimote accessories. These have a female connector that you will need to cut off. Strip the outer coating of the extension cable to access the wires inside.

For prototyping purposes, I have soldered the wires to a male header.

Note that the device-detection wire on the cheap extension cables do not actually work (they are connected directly to +3.3V), thus I am unable to truly detect a device-connect or disconnect event in the software.

The signals are:
  • Ground, connect to ground on the USnooBie
  • +3.3V power supply, connect to USnooBie's +3.3V pin
  • SDA (this is the I2C data line), connect to PC4 on USnooBie
  • SCL (I2C clock line), connect to PC5 on USnooBie

Make sure that USnooBie is supplied with 3.3V by using the voltage selection jumper. This is so that the internal pull-up resistors (on the I2C lines) of the ATmega328P will use 3.3V instead of 5V. Also the Wii Classic Controller must be powered with 3.3V as well.


Step 8: TWI / I2C Explained

I2C stands for Inter-Integrated Circuit. I2C busses are also known as TWI for Two Wire Interface, since it uses only two wires.

Related Readings:
On a TWI bus, the two signal wires are SDA and SCL, basically data and clock. These signals are open drain (meaning its logic level is either high impedance or low, it cannot ever be high), but there must be a pull-up resistor on each of these signals (we are using the AVR's internal pull-up resistors). This is significant because any device on a TWI bus can drive the signals low at any time, so the signal can only become high when all the devices allow it to become high. This allows devices to detect when the bus is occupied ("arbitration using SDA") and also allow a slow device to dictate the speed of the clock, or even pause a transmission if the slower device is too busy (doing this is called "clock stretching". These facts makes the TWI bus good for communication between a bunch of chips using only two wires.

Every transaction is between a master (the one driving the clock signal) and a slave device. Every transaction starts with a "start condition" and ends with a "end condition". A start condition is when the bus master drives SDA low first, then driving SCL low second. An end condition is when the master releases the TWI bus by releasing SCL and then releasing SDA.

After the start condition, the master has to choose which device to talk to by sending a 7 bit address byte. The 8th (last being sent) bit indicates whether or not the master wishes to read (1) from or write (0) to the slave being addressed. If the master is writing, it will then send more data. If the master is reading, it will release the SDA line so the slave sends data (but the master is still driving the clock). When addressed

All bytes are sent MSB first (most significant bit first). Every byte is optionally ended by an acknowledgement/nacknowledgement. Check the device datasheet to see what the device will expect or will send back. Usually, to quote Wikipedia: "If the master wishes to write to the slave then it repeatedly sends a byte with the slave sending an ACK bit. (In this situation, the master is in master transmit mode and the slave is in slave receive mode.) If the master wishes to read from the slave then it repeatedly receives a byte from the slave, the master sending an ACK bit after every byte but the last one. (In this situation, the master is in master receive mode and the slave is in slave transmit mode.)"

More intricate details are usually specific to a particular device, and such information will come from its datasheet.

When I use I2C/TWI with AVR microcontrollers, I use the low level layer of the "Wire" library for Arduino. The Wire library is the C++ wrapper for the lower level "twi.c" and "twi.h" module, which I modify slighly and compile into my own code (since I don't usually use C++). It takes care of almost everything.

The Wii Classic Controller has a I2C address of 0x52, keep that in mind. Using "twi.c" and "twi.h", to send some data to the Wii Classic Controller, start by creating a byte array containing the data to be sent, and then pass that to the "twi_writeTo" function, along with the destination address, the amount of data to send, and tell it "wait until all data is sent". The code will look like:
unsigned char dataArray[3] = { 'a', 'b', 'c', }; twi_writeTo(0x52, dataArray, 3, 1);
To read three bytes, use the function "twi_readFrom", and tell it the address, the data is saved to a array you pass in, and you specify the amount of data. The code looks like:
unsigned char dataArray[3]; twi_readFrom(0x52, dataArray, 3);

Step 9: Reading the Wii Classic Controller

The Wii Classic Controller has an address of 0x52, which must be specified as the first byte of all I2C transmissions so it knows that it's being spoken to.

In our project source code, we initialize the Wii Classic Controller by:
  1. Initializing the TWI/I2C module of the AVR, enabling the pull-up resistors
  2. Sending it 0x40 0x00
  3. Sending it a sequence of false encryption keys, so the decryption is easy
The data traveling on the bus after this initialization have been performed will still be encrypted, but since we've just gave it the fake keys, we know exactly how to decrypt it. See source code for details.

In the main loop of the code, data is read from the Wii Classic Controller by
  1. Sending it 0x00, this sets a read pointer
  2. Reading 6 bytes of data from it
Here's the data format for the 6 bytes of data that we read from the Wii Classic Controller:
Bit
Byte76543210
0RX<4:3>LX<5:0>
1RX<2:1>LY<5:0>
2RX<0>LT<4:3>RY<4:0>
3LT<2:0>RT<4:0>
4BDRBDDBLTB-BHB+BRT 1
5BZLBBBYBABXBZRBDLBDU

LX,LY are the left Analog Stick X and Y (0-63), RX and RY are the right Analog Stick X and Y (0-31), and LT and RT are the Left and Right Triggers (0-31). The left Analog Stick has twice the precision of the other analog values.

BD{L,R,U,D} are the D-Pad direction buttons. B{ZR,ZL,A,B,X,Y,+,H,-} are the discrete buttons. B{LT,RT} are the digital button click of LT and RT. All buttons are 0 when pressed.

Credit to http://wiibrew.org/wiki/Wiimote/Extension_Controllers for this valuable information.

In our project, the data format must be sent through USB in this format:
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Button Button Button Button Button Button Button Button
Byte 1 Button Button Button Button Button Button Button Button
Byte 2 Left Stick X Axis as Signed Char Integer
Byte 3 Left Stick Y Axis as Signed Char Integer
Byte 4 Right Stick X Axis as Signed Char Integer
Byte 5 Right Stick Y Axis as Signed Char Integer

Our source code does a bit of simple binary math to perform the transformation. Note that buttons needs to be 1 when pressed so we invert the button data from the Wii Classic Controller.
When the microcontroller starts up, it also takes a reference center reading for the joysticks to calibrate it, this center value is combined with a low-pass-filtered offset to eliminate noisy readings.

See the whole source code for more details.

I've also attached a logic analyzer session file ( .logicsession file, can be viewed with Saleae Logic1.1.9), and a text format log file of I2C communications with the Wii Classic Controller. You can download these and study the communication in-depth.

Step 10: Compiling and Loading the Code

The project can be opened with AVR Studio 5 or AVR-Project-IDE, open it and build the project. The hex file that is generated can be loaded into the ATmega328P using AVRDUDE.

If you are using the USnooBie, then you can follow this guide:

Usage Guide


This is the short version of the official usage guide, go visit the official usage guidefor more details.



To enter the bootloader, hold down the bootloader-activation button, then press and release the reset button, then release the bootloader-activation button. The bootloader should appear to your computer as an USBasp programmer, so you may now use it as though you were using an USBasp with AVRDUDE.

A typical AVRDUDE command would start with "avrdude -c usbasp -p atmega328p", and to load a hex file into flash memory, it looks like "avrdude -c usbasp -p atmega328p -U flash:w:filename.hex". You will not be able to modify any fuse-bits, which prevents you from "damaging" the bootloader.

There's a good chance that you'll require the USBasp drivers in order for the USBaspLoader bootloader to work. The drivers can be found here

Step 11: Finishing Up

I purchased a small plastic enclosure, and a prototyping circuit board. In the front of the enclosure, I cut a hole for the USB connector and the Wii extension connector. I glued the Wii extension connector into the correct location on the circuit board and soldered the wires to the circuit board. I replicated the USnooBie circuitry onto the circuit board. The circuit board is then mounted into the enclosure. This created a neat final finished product.

To replicate the circuit, see the downloads page for USnooBie, it's open source and all the schematic and PCB files are available.

This step is optional, depending on how much money you want to spend.

Step 12: Testing and Using

Plug it in and it should cause your operating system to automatically install the drivers required. If the vendor ID and product ID is causing problems (conflicts with older drivers, etc), go modify them in "usbconfig.h", recompile the project, and re-program the AVR with the new recompiled hex file.

Do not disconnect the Wii Classic Controller from the circuit while it is plugged into USB. If you do, you might need to disconnect and reconnect the USB cable in order to force a reset. This is because the cheap extension cable connector does not allow me to implement device detection properly. In the source code, I'm depending on the watch-dog timer to automatically perform this reconnection, the watchdog timer will timeout in the TWI function while waiting for the rely from the Wii Classic Controller and cause the reset, which causes the simulated reconnection.

Open up the joystick thing in Window's control panel and watch it work.



If you want to use it in a video game, be sure to map all the buttons first.

If a joystick axis is inverted, then you can go into the source code and multiply its value by negative one. In fact, you can do a lot of creative things in the source code! You can add scaling to the joysticks, or rapid tapping behaviour to the buttons if you want.

Step 13: Bonus: Keyboard and Mouse

By modifying the HID report descriptors slightly, we can also turn this project into a USB keyboard or USB mouse, or a combination device. I have attached all of the source code.


USB Mouse


The HID report descriptor has been modified to indicate that the usage is a mouse pointer. The X and Y movements are now relative instead of absolute. There are only three bits used for the mouse buttons (left click, right click, middle click), there is also vertical mouse wheel scrolling, and horizontal scrolling (doesn't really work without Logitech drivers, as it's not a standard feature).

The data structure becomes something like this:

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Useless Useless Useless Useless Useless Middle Button Left Button Right Button
Byte 1 X Axis Relative Movement as Signed Integer
Byte 2 Y Axis Relative Movement as Signed Integer
Byte 3 Vertical Scroll as Signed Integer
Byte 4 Horizontal Scroll as Signed Integer


The corresponding C data struct looks like:
static struct mouse_report_t { uint8_t buttons; // button mask ( . . . . . M L R ) int8_t x; // mouse x movement int8_t y; // mouse y movement int8_t v_wheel; // mouse wheel movement int8_t h_wheel; // mouse wheel movement } mouse_report;

The HID report descriptor looks like
PROGMEM char usbHidReportDescriptor[61] = { // make sure the size matches USB_CFG_HID_REPORT_DESCRIPTOR_LENGTH in usbconfig.

Some minor changes were made in "usbconfig.h", mainly the vendor and product IDs were changed to clone a Logitech brand mouse. The product and manufacture strings were changed but this does not take effect in Windows due to the fact that Windows update finds the product information from Windows Update. The length of the HID report descriptor is also changed to match the size of the array.

USB Keyboard


The HID report descriptor has been modified to indicate that the usage is a keyboard. This descriptor is slightly more complicated. We send 8 bytes of data, the first byte is a modifier byte containing bit flags for the shift, CTRL, ALT, and other modifier keys. The 2nd byte is useless. The last 6 bytes contain key codes (not ASCII) of the keys being pressed.


The C data struct looks like:
static struct keyboard_report_t { uint8_t modifier; // bit flags for shift, ctrl, and alt, and other stuff uint8_t reserved; // useless for now uint8_t key[6]; // HID keycodes } keyboard_report;

The HID report descriptor looks like
PROGMEM char usbHidReportDescriptor[63] = { // make sure the size matches USB_CFG_HID_REPORT_DESCRIPTOR_LENGTH in usbconfig.

This descriptor is sort of "standardized" so that it works without an operating system. "usbconfig.h" contains some changes to the interface subclass and protocol to enable "boot protocol" so that it works without an operating system (such as when you are in BIOS menus).

A V-USB function called "usbFunctionWrite" is also created to handle the situation when the computer wants to tell the keyboard to turn on or off status LEDs, such as the CAPS LOCK, NUM LOCK, or SCROLL LOCK. The function is written but it doesn't actually do anything.

// data from the computer is handled here // this is actually going to be stuff like NUM LOCK, CAPS LOCK, and SCROLL LOCK LED data unsigned char usbFunctionWrite(unsigned char *data, unsigned char len) { // ignore this data return len; }

The function "usbFunctionSetup" is a little longer to handle some more stuff such as changing the current protocol, and calling "usbFunctionWrite".

Some other minor changes were made in "usbconfig.h", mainly the vendor and product IDs were changed. The length of the HID report descriptor is also changed to match the size of the array.

USB Combo Device


I know how to write the descriptor and data structures for a USB combination device (all-in-one keyboard-mouse-gamepad) but the performance is kind of bad. However, it does sort of work.

The trick is using "Report ID" inside collections of the descriptor. Each collection represents a different device with a unique ID. The ID is sent at the top of each report. So the descriptor looks like this (really long):
PROGMEM char usbHidReportDescriptor[176] = { // make sure the size matches USB_CFG_HID_REPORT_DESCRIPTOR_LENGTH in usbconfig.
And the structures now include a report ID:
static struct keyboard_report_t { uint8_t report_id; uint8_t modifier; // bit flags for shift, ctrl, and alt, and other stuff uint8_t reserved; // useless for now uint8_t key[6]; // HID keycodes } keyboard_report; static struct mouse_report_t { uint8_t report_id; uint8_t buttons; // button mask ( . . . . . M L R ) int8_t x; // mouse x movement int8_t y; // mouse y movement int8_t v_wheel; // mouse wheel movement int8_t h_wheel; // mouse wheel movement } mouse_report; static struct gamepad_report_t { uint8_t report_id; uint16_t buttons; int8_t left_x; int8_t left_y; int8_t right_x; int8_t right_y; } gamepad_report;

Inside "usbFunctionSetup", we need to check which report is requested by checking "wValue" for the report ID:
// check report ID requested if (rq->wValue.bytes[0] == 1) { usbMsgPtr = &keyboard_report; return sizeof(keyboard_report); } else if (rq->wValue.bytes[0] == 2) { usbMsgPtr = &mouse_report; return sizeof(mouse_report); } else if (rq->wValue.bytes[0] == 3) { usbMsgPtr = &gamepad_report; return sizeof(gamepad_report); }

Before sending each report, the report ID is set in the data structure.

keyboard_report.report_id = 1; // set report ID so computer knows what data struct is sent // wait until ready to send, then send it while (1) { usbPoll(); if (usbInterruptIsReady()) { usbSetInterrupt((unsigned char *)(&keyboard_report), sizeof(keyboard_report)); break; } }
And in the end, windows does recognize this device as a combination device.

Step 14: Learn More

I've become pretty handy with the USnooBie. It is very easy for me to turn this project into a USB mouse instead, or even create a USB combination device that is a mouse, gamepad, and keyboard all at once. I have already done this over and over again using the Wii Nunchuk and PlayStation controllers. USnooBie makes this really easy.

On my website, I have plenty of tutorials showing you how to make these things, with examples using RFID readers, PlayStation controllers, optical mouse sensors, etc.

https://www.instructables.com/id/USB-RFID-Reading-Keyboard/ < Please watch me! I've put an insane amount of effort into this video.
http://www.frank-zhao.com/usnoobie/tut_proj.php

Also try to apply the technique used to read the Wii Classic Controller to your other projects. I originally purchased it as a control method for a RC radio transmitter. Wii accessories are an extremely inexpensive way to add a solid input device to any project.

Be the First to Share

Did you make this project? Share it with us!

Recommendations

  • Retro Tech Challenge

    Retro Tech Challenge
  • Halloween Contest

    Halloween Contest
  • 3D Printed Student Design Challenge

    3D Printed Student Design Challenge
Sours: https://www.instructables.com/USB-Wii-Classic-Controller/
  1. Lexus champaign, il
  2. Bulgarian makarov
  3. Banshee rear hub
  4. Antonyms for circuit



How to Soft-Mod WiiU Pt 3 Use ANY Controller to Play! (Ps4, Xbox, Logitech, Keyboard + Mouse)

Video taken from the channel: GameInCanada




How to use PS4 Controller on the nintendo wii

Video taken from the channel: Wonderland_War Gaming




How to use ps3 controller on Nintendo wii (Nintendon’t )

Video taken from the channel: aljoin




Unboxing Cybergadget USB to Wii/Wii U Controller Adapter & Test [Manjoume]

Video taken from the channel: Manjoume




How To Connect PS4/PS3 Controller To Nintendon’t (Guide 2017!)

Show Description
How To Connect PS4/PS3 Controller To Nintendon't (Guide 2017!)

Hi guys, Tech James here,.
In this video, I’ll explain how to connect a PS3 or PS4 controller to Nintendon’t on the Wii, to play GameCube ISO games, this is great if you don’t own a GameCube controller! Make sure you connect your controller after the game has loaded, then double click the PS button..
This video is for educational purposes only..
➤ (Nintendon’t Tutorial): https://www.youtube.com/watch?v=sSTt49H06cw.
➤ (CHEAP STEAM GAMES): https://www.g2a.com/r/techjames.
Music: Unknown Brain Roots (https://www.youtube.com/watch?v=cexPpgmaXhI).
Please Like + Subscribe.
Copyright Disclaimer Under Section 107 of the Copyright Act 1976, allowance is made for “fair use” for purposes such as criticism, comment, news reporting, teaching, scholarship, and research.

Video taken from the channel: Tech James




USB Controller works on Nintendont for Wii

Video taken from the channel: EEK Turk




How to mod your N64 controller to Wii (U) remote (Plus)

Video taken from the channel: W3Electronics


Hello everybody, I’m Dars or DPadDars, and today I will be showing you how to connect a USB controller to your Wii U using Homebrew Launcher and HIDtoVPAD! Please like and subscribe if this helped!*this video includes complete usb gamepad/controller setup & configuration in the most easiest way. *JUST WATCH THE VIDEO TILL THE END & PLAY YOUR FAVOURITE NINTENDO WII & NINTENDO GAMECUBE GAMES.

Turn the Wii U console off. Ensure the connector on the USB device is oriented correctly. Insert the USB connector straight into a USB port on the Wii U console.

USB connector being inserted into. It’s possible to use a USB pad. Easy, no. But possible.

What you’d have to do would be essentially write a driver for that gamepad and embed it into the IOS that the homebrew uses, and then use the homebrew to call on it. That or else you could try replace the Classic Controller or whatever with your USB gamepad. Just a quick video to show people how I use the PlayStation 2 joypad (Dualshock 2) in my Super Smash Bros Brawl hacked gameplays on Nintendo Wii. Music is from Sonic Robo Blast 2, that game is.

Note: Compatible games will feature the following icon either on the Wii Shop Channel or on the game’s product packaging. Complete these steps. Feed the cord on the wrist strap through the connector hook, and insert the Classic Controller plug into the External Extension Connector on the bottom of the Wii.

How to Connect a Wii Remote to a Samsung Galaxy S3 Duration: 5:23. Tech Fusions 150,059 views. 5:23. The Wii’s *Awful* Prototypes Duration: 10:37. Thomas Game Docs 1,112,302 views.

How to Soft-Mod WiiU Pt 3 Use ANY Controller to Play! (Ps4, Xbox, Logitech, Keyboard + Mouse) Duration: 21:31. GameInCanada 93,102 views. The Wii Remote will remain on and connected to Dolphin, but the game will believe it is disconnected. To “reconnect” the Wii Remote, go to Tools -> Connect Wii Remotes -> Connect Wii Remote # or use a hotkey corresponding to it (example the Windows default for Wii Remote 1 is Alt-F5), or simply press a button on the Wii Remote.

Press the Power Button on the Wii console to turn it on. Open the SD Card Slot cover on the front of the Wii console. If you are using a Wii mini, the SYNC Button is located on the left hand side next to the battery compartment. The SYNC Button is a darker shade of red than the console. Open up Cemu, head to the Input section, select “Emulated Device” either as WiiU GamePad (recommended) or the WiiU Pro Controller.

Next up select “Controller API” as Xinput and then select your controller in the drop down menu (most likely it will show up as “Controller 1” unless you got more connected. One of the few technical advantage the Nintendo Wii has against its high-tech rival the XBox 360 is that it allows users to browse the web on their console. Trying to do so using only a Wiimote, however, is impractical.

Did you know that you could use a USB keyboard instead? This video will show you how to connect a USB keyboard to your Wii, making it MUCH easier and more practical to use the.

List of related literature:

This port is deprecated in the new Wiimotes (RVL-CNT-01-TR) and will no longer work on devices sold after December 2011.

“Pro Android Games” by Vladimir Silva
from Pro Android Games
by Vladimir Silva
Apress, 2012

To do this, you need an official game-pak to plug into the bottom of the adapter, which will authenticate the process.

“Game Preview” by Nicolae Sfetcu
from Game Preview
by Nicolae Sfetcu
Nicolae Sfetcu, 2014

Connect the rectangular gray end of the Wii A/V cable to the back of the Wii in the slot labeled AV Multi Out (see Figure 2-3).

“Wii For Dummies” by Kyle Orland
from Wii For Dummies
by Kyle Orland
Wiley, 2010

The onlydifficultpart is findingapotentiometer that is physically the right sizeandmounting it.You canalso use an analog­based gamepad, such as the Microsoft SidewinderDual Strike, which essentially uses5K pots and connects via the USB port.

“Project Arcade: Build Your Own Arcade Machine” by John St. Clair
from Project Arcade: Build Your Own Arcade Machine
by John St. Clair
Wiley, 2011

Assuming that just a single gamepad is connected, you need only get the zeroth element of the Array, as follows:

“Beginning Java Game Development with LibGDX” by LEE STEMKOSKI
from Beginning Java Game Development with LibGDX
by LEE STEMKOSKI
Apress, 2015

Most modern game controllers connect via USB.

“Mastering Microsoft Windows Vista Home: Premium and Basic” by Guy Hart-Davis
from Mastering Microsoft Windows Vista Home: Premium and Basic
by Guy Hart-Davis
Wiley, 2007

In order to use other controllers as a USB gamepad, you will need a hardware converter.

“Retro Gaming Hacks: Tips & Tools for Playing the Classics” by Chris Kohler
from Retro Gaming Hacks: Tips & Tools for Playing the Classics
by Chris Kohler
O’Reilly Media, 2005

supports LAN play using the Nintendo GameCube Broadband Adapter, allowing 16 players to compete simultaneously.

“Mario Titles” by By Wikipedians
from Mario Titles
by By Wikipedians
PediaPress,

You need a version of the console cable that has USB connectors on either end.

“Cisco Networking Essentials” by Troy McMillan
from Cisco Networking Essentials
by Troy McMillan
Wiley, 2015

The Wiimote uses this protocol to connect to the Wiiconsole or a PC.

“Coding4Fun: 10.NET Programming Projects for Wiimote, YouTube, World of Warcraft, and More” by Dan Fernandez, Brian Peek
from Coding4Fun: 10.NET Programming Projects for Wiimote, YouTube, World of Warcraft, and More
by Dan Fernandez, Brian Peek
O’Reilly Media, 2008
Sours: https://rdtk.net/media/how-you-can-connect-a-usb-joypad-to-some-wii/
USB Controller works on Nintendont for Wii

Classic controller to USB adapter - V3

An adapter for connecting a Classic controller (or other Wiimote accessories, such as guitars) to an USB port.

Description

This adapter brings high quality modern Nintendo controllers to your PC. The Classic controller has plenty of buttons and axes making it an excellent option for a wide variety of games. Wiitars are also supported and with its very low latency, this is the adapter of choice for use with Clone Hero.

advXarchThis adapter is built using advXarchtechnology.

Specifications:
  • Supported controllers: Classic controller, Classic controller Pro, NES/SNES Classic edition controllers, Nunchuk, Wii Guitars, Wii Drumkits and Wii Turntables
  • Low latency (Default 6ms, min. 2ms) (more info)
  • Works under Linux, Mac OS X and Windows
  • Updateable firmware
  • Some aspects of the adapter are configurable:
    • The D-Pad can act as buttons or axis
    • Nunchuk accelerometers can be enabled as axes
    • Left/Right joysticks can be swapped
    • The analog triggers can be disabled (new in firmware 2.1)
    • Mouse and joystick modes
    • Configurable polling rate
  • 2M (approx. 6ft) USB cable included
Management tool:(more info)
  • Easy to use user interface able to manage several adapters.
  • Adapter firmware version display
  • Firmware update function
  • Type of connected controller display
  • Adapter configuration
Drivers:
  • None! Uses standard drivers included with supported operating systems.

Buy here

In stock : Ships within 5 business days unless noted otherwise (out of stock, pre-order, holidays, etc).
Item #ADAP-1XWUSBMOTE_V3
DescriptionClassic controller to USB adapter V3 (w/advXarch)
product picture
Price
1$24.43 Each
2+$21.99 Each (10% OFF)

We normally ship within 5 days (excluding week-ends and holidays) after payment.
Prices are in US dollars.

Other ways to buy

Resellers

Local alternatives to ordering directly from raphnet. Potentially faster or easier (no customs) delivery. Service in other languages and additional payment methods may also be available.
Resellers are free to set a price that makes sense for them and their target market. Not all resellers may have inventory at the moment.
IMPORTANT: This is not a complete list. If something does not appear here, it simply means that we did not get the chance (or the idea) to test it, or that no one let us know that it works.

Help us improve this page by sending test results by email to [email protected]
Thanks!

Tested Controllers

ModelTested bySupportedComments
Classic Controller (RVL-005)raphnet.Yes
Classic Controller Pro (RVL-005(-02))raphnet.Yes
Nunchuk (RVL-004)raphnet.Yes
3rd party wireless Nunchukraphnet.Yes
Classic controller pro (cheap clone)raphnet.Yes
NES Classic Edition Controller (CLV-002)raphnet.Yes
SNES Classic Edition Controller (CLV-202)raphnet.Yes
Hori Pokemon Battle Pad for Wii/Wii U (WIU-079)raphnet.Yes
PDP Wired Fight Pad for Wii U (Wario) (085-006)raphnet.Yes
Wii U fightpad (Gamecube-shaped)UserYes
Tatsunoko Vs Capcom Arcade Stick U fightpadUserYesDirectional control stick recognized as analog stick
Tekken Tag Tournament 2 Arcade FightStick Tournament Edition 'S' for Wii UUserYes
Wireless Turbo Controller for NES Classic edition (no brand, no part number)raphnet.YesSupport added in firmware v2.1.1
8Bitdo SN30 2.4G Wireless Gamepad for SNES Classic Editionraphnet.YesSupport added in firmware v2.1.1
8Bitdo SF30 2.4G Wireless Gamepad for NES Classic Editionraphnet.YesSupport added in firmware v2.1.1
8Bitdo N30 2.4G Wireless Gamepad for NES Classic Editionraphnet.YesSupport added in firmware v2.1.1
RedOctane Les Paul Controller for Nintendo Wii (Guitar), model 95125.805raphnet.Yes
RedOctane Wireless Controller for Nintendo Wii (Guitar), model 95455.805raphnet.Yes
Activision Wireless Guitar Controller for Nintendo Wii, model 95911.805raphnet.Yes
Logitech Wii Wireless Guitar ControllerUserYes
Warriors of Rock guitar (96158.805)UserYes
NYKO Front Man Wii GuitarUserNo
RedOctane Wireless Drum Controller for Nintendo Wii (95521.805)UserYesSupport added in firmware v2.1.2
Logitech Wireless Drum Controller (R-R0004)UserYesSupport added in firmware v2.1.2
Club Nintendo SNES Wii controllerUserYes
Fake Classic SNES controllerUserNoDetected as a Nunchuk and non-functional

Tested Systems

SystemTested bySupportedComments
Windows 10raphnet.Yes
Linuxraphnet.Yes
Mac OS Xraphnet.Yes
macOS Big SurUserYesTested on a 2020 MacBook Air with M1 Apple Silicon chip
Raspberry Pi (Linux)raphnet.Yes
FreeBSDUserYes
MiSTer FPGAUserYes
Nintendo SwitchUserNoThe switch does not support standard USB HID joysticks
Playtation 2UserNoWe do not know if there are games which would recognize the adapter, but even if they did, unless they also provided a way to configure the buttons, the buttons (such as the frets on a guitar) could be in a scrambled order.
NVidia ShieldUserNoHas been reported as not working properly, details not known.

Q: Can I use multiple adapters for multiplayer games?
A: Yes, you can connect many adapters to the same computer and each one will be recognized as a separate controller.

Q: Is the adapter USB 2.0 or USB 3.0? Can I connect it to an USB 3.0 port?
A: The adapter is USB 2.0. It can be connected to USB 2.0 as well as USB 3.0 ports.

Q: I see the adapter has a mouse mode. How does this work?
A: Once mouse mode is enabled using the adapter manager, the pointer will be controller by the joystick on Classic controller, Classic controller pro and Nunchuk controllers. The uDraw and Drawsome tablets can also be used as a mouse.

Q: What are the differences with the old (V2) version?
A: It's mostly a new mechanical design with a built-in connector. Also, the included USB cable is longer and better suited for use with Guitars.

Q: Is the performance equal to the previous (V2) version?
A: Yes, it is exactly the same because this new version runs the same firmware on almost identical electronics.

DescriptionLink
Adapter management/update toolsView
Beta firmware pagePress here
Sours: https://www.raphnet-tech.com/products/wusbmote_1player_adapter_v3/index.php

For wii controller usb

Can I use USB controller on Wii?

Can I use USB controller on Wii?

The Wii console is equipped with USB plugs that allow for certain controllers and joypads to be plugged into the system when the wireless controllers are not compatible. The joypad will now be connected, and it will work once the Wii is turned on.

How do I connect a PowerA PS3 controller without USB?

As long as the controller’s battery is charged, it can be connected by simply pressing the PlayStation button and waiting. The four LEDs at the top – generally used to designate controller number – will blink briefly as the DualShock 3 searches for nearby devices it can connect to.

How do you use a Nintendont controller on ps3?

Long usb to mini usb cable plugged into the wii and the ps3 controller, and it will work….Ignore everyone else.

  1. Download controllers.txt from Nintendont’s options menu.
  2. Plug it into the USB port and plug the usb micro into your ps3 or ps4 controller.
  3. Make sure native control is off and now you’re playing!

Can u connect a ps4 controller to a Wii?

No you can’t. It seems really strange on this one as the idea of “USB” is that it’s supposed to be “Universal Serial Bus” – i.e. USB is supposed to be universal and one USB device is supposed to work with all other USB devices.

Can a PS3 controller connect to the PS3 wirelessly?

Your controller should now be connected to the PS3 wirelessly. Wireless functionality is only available on official Sony DualShock 3 controllers. On unofficial controllers, you’ll need to leave the cable plugged in. 7

Where is the charging port on a PS3 controller?

When connecting a new controller, the PS3 cannot be in Standby mode. Connect the controller’s charging cable to the controller. You’ll find the charging port for the cable, which is a mini-USB cable, in the front of the controller’s housing (between the triggers).

Is the PowerA Nintendo Switch Pro Controller good?

PowerA’s stylish line of Switch controllers feel great, and they’re a fraction of the price of Nintendo’s Pro Controller. PowerA’s stylish line of Switch controllers feel great, and they’re a fraction of the price of Nintendo’s Pro Controller. The Nintendo Switch is fantastic, but it does have some drawbacks.

Where do I Find my PS3 controller on my computer?

Check the “Wireless Controller” option. You’ll see a list of all devices attached to your computer (e.g., keyboards, mouses, webcams, etc.). Your PS3 controller is the option marked “Wireless Controller (Interface [number])” where the number pertains to the USB port to which the controller is attached.

Your controller should now be connected to the PS3 wirelessly. Wireless functionality is only available on official Sony DualShock 3 controllers. On unofficial controllers, you’ll need to leave the cable plugged in. 7

When connecting a new controller, the PS3 cannot be in Standby mode. Connect the controller’s charging cable to the controller. You’ll find the charging port for the cable, which is a mini-USB cable, in the front of the controller’s housing (between the triggers).

Is the power a PS3 controller 5 star?

(As for the fifth star, if Power A can fix two out of three, the cord length, the sharpness, and the lack of motors, but only bump the price by one to three bucks, if necessary, I think that’d be a five star product, for the price range. I don’t know if that’s realistic, but it’s the best advice I’ve got.

Check the “Wireless Controller” option. You’ll see a list of all devices attached to your computer (e.g., keyboards, mouses, webcams, etc.). Your PS3 controller is the option marked “Wireless Controller (Interface [number])” here. The [number] section pertains to the USB port that your controller is using.

Sours: https://boardgamestips.com/collectible-card-games/can-i-use-usb-controller-on-wii/
Nintendo Wii + Nintendont + Gamecube Como jogar com o controle USB de PC.

Retro Controller Adapters

This page describes ways to use controllers from classic game systems on modern consoles and emulation setups.  It’s my opinion that using a console’s original controller can sometimes be as important as display lag, for preserving the original game experience.  Luckily, there’s plenty of adapters that allow you to use original controllers in variety of newer environments!

USB Adapters

Emulation boxes generally use USB for their controller support, which means getting a high-quality USB converter is an excellent addition to your setup.  Also, the PS3, Xbox and many other consoles can use a USB controller as well!  Many of the stores listed in the GC&Wii section below offer extremely low-latency USB adapters, as well as their console-to-console variants.

Bliss Box:
While the adapters below are all great, the Bliss Box is a device that can convert controllers from almost any console to USB!  If you’re looking for one solution for everything, please check out their page:  https://bliss-box.net/store/



Gamecube & Wii Adapters:

I find that using original controllers is a great alternative to using the official Wii Classic Controller or Pro controller.  As good as the pro controller is, it doesn’t feel like the controllers from the original systems, which in my opinion is a huge part of experiencing the classic games.

There are two types of retro controller adapters available: Some plug into the Gamecube’s controller port and others plug into the bottom of the Wiimote. The Gamecube port versions are only compatible with Gamecube systems and original Wii’s that have the GC controller ports on top. The Wiimote versions are compatible with both the Wii and Wii U.  Please note that none of these adapters require configuration, they just work.  Anyone who has ever had to set up button mappings knows how nice it is to have something pre-configured.  Here’s a list of all the ones I’ve found, broken up into two categories:

GameCube Adapters(for Gamecube and compatible Wii systems)

These adapters plug into your Gamecube, or Wii with GC controller ports.  They will work with every Virtual Console game, as well as any emulators available.  They will not work with the Wii U, or WiiWare games.  Since these are direct conversions, they can offer lag-free gameplay.

Retrousb.com offers NES and SNES adapters that work great. I own these and have never noticed any lag. The only downside is that they map the Select button to “Z”, so this might cause issues when using the Game Boy Player:
http://www.retrousb.com/index.php?cPath=22

Raphnet Technologies offers many different adapters for each system, including an adapter for the Genesis controller, which is also compatible with the SMS and Atari controllers. Here’s links to the individual cables, but check out their site for plenty of other adapters for each system:
Genesis  – NES  – SNES  – N64

G-Tron 4-in-1 adapter – This was the original retro adapter I owned. It works, but it has a noticeable lag. Also, Genesis 6 button controllers don’t work (3-button work fine) and N64 controllers don’t work at all.

Wiimote Adapters (for Wii and Wii U systems):

These adapters will work with the Wii and Wii U, by plugging into the bottom of the Wiimote.  They are compatible with everything the official Wii Classic Controller will work with, including actual Wii and Wii U games, as well as Virtual Console and WiiWare games!   Please note, since a digital conversion of the commands is necessary, there will always be some lag, even if it’s just a fraction of a millisecond.  Some adapters may be so fast that it’s not noticeable at all, but unfortunately, I haven’t been able to try any myself.  Please contact me if you have any experience with them and an offer an opinion.

Raphnet Technologies offers adapters that plug directly into the Wiimote, in addition to their Gamecube adapters:
Gamecube  – NES  – SNES  – N64

Wii RetroPad Adapter 2 – This is one adapter that can handle inputs from many different controllers! It comes with a Genesis controller port built in, but you can buy adapters for many systems. It currently supports controllers from NES, SNES, N64, Playstation, Gamecube, Neo Geo CD, Saturn and TurboGrafx 16! It’s an open source project, so you can either buy one from them, or decide to build your own using their manual. Here’s where to purchase:
http://shop.brunofreitas.com

Mayflash Adapters – A company called Mayflash offers a few adapters, but they can be hard to find.  Also, their SNES/NES to Wii adapter uses a different port for the NES, so you’d have to make your own NES input cable.  If your main goal is to use your NES controller, I’d chose a different company:
Gamecube  –  Saturn/N64/Playstation  –  Playstation  –  SNES/NES

Gamecube to WiiMote Adapter – Here’s an adapter that allows you to plug your GC controller into the Wiimote. I imagine you can use this along with the Gamecube adapters listed above, but I don’t own one to test.



I hope this page was a help! Feel free to check out the main page to see what else this site has to offer!



Sours: https://www.retrorgb.com/wiiadapter.html

You will also like:

.



907 908 909 910 911
